DS-PM1-O1L-WE

Hikvision DS-PM1-O1L-WE is an 868 MHz two-way wireless relay module for low-voltage circuit control. Its 7 to 24 VDC device input is separate from the relay-output DC rating. Confirm the matching panel, load and wiring, then select quantity for a supply-only enquiry.

Hikvision · Full reference: DS-PM1-O1L-WE

Choose quantity

Manufacturer reference

Manufacturer details describe the cited version. Confirm the exact unit and intended system.

Control and wireless references

Device class: Relay Module
Control purpose: Low-voltage electrical power supply open/close control. This peripheral is a relay module, not an alarm control panel.
Manual control reference: APP, keypad and keyfob control are listed. Confirm the matching panel, device combination and configuration.
Scenario triggers: Alarm, operation, fault, schedule and manual scenario triggers are listed. Configure and test the required event behaviour.
RF frequency: 868 MHz in the exact RF frequency row. Match the panel and peripheral radio variants before selection.
RF communication: Two-way wireless communication is listed.
RF modulation: 2GFSK modulation is listed.
Wireless security reference: AES-128 encryption is listed. Confirm the actual protocol, firmware and configured system security separately.

Low-voltage I/O and indications

Device power input: 7 to 24 VDC device supply. This input range is separate from the relay contact/load rating.
Relay output count: One relay output is listed.
Relay contact reference: NO/NC contact options are listed. Confirm the circuit and load wiring.
Relay DC rating: The relay-output row lists 0 to 36 VDC and maximum 5 A. Check load type, inrush, protection and wiring before use; this is a DC rating, not an AC or mains-switching claim.
Alarm input count: One alarm input for tamper is listed.
Alarm input modes: NO/NC alarm-input modes are listed. Confirm how the external tamper circuit is wired.
Learning button: One learning button for registration is listed.
Debug serial connection: One serial port for debugging is listed. This does not establish an operational customer API or an implemented integration.
LED indicator count: Three LED indicators are listed.
Registration and signal indication: Green/red registration and signal indication is listed.
Power indication: Green power indication is listed.
Relay indication: Blue relay-status indication is listed.

Environment and physical selection

Operating temperature: -10 to 55 °C in the cited sheet. Check the actual enclosure and environment.
Operating humidity: 10% to 90% in the cited sheet. A condensation tolerance is not specified.
Mounting method: Wall mounting is listed. Confirm enclosure, fixings and installation clearances.
Overall dimensions: 38 mm wide × 25 mm high × 18 mm deep. Allow separate wiring and mounting clearance.
Shell material: Plastic shell is listed.
Colour reference: White in the cited sheet. Confirm the actual supplied variant.
Weight reference: 28.5 g in the weight row; the sheet does not label it as a packed or net mass.

Selection notes

References for DS-PM1-O1L-WE in the cited manufacturer sheet. Confirm actual hardware, firmware, matching panel, radio variant and local requirements before selection.
The device input and relay-output ratings are separate. Confirm DC load, inrush, protection and wiring; no AC or mains-switching capability is established.
A debug serial connection does not establish a customer integration API. The manufacturer sheet does not establish a qualified site radio range.
Keep the complete WE suffix. WB and other regional variants are separate; frequency alone does not prove compatibility or Malaysian radio approval.
ISD supplies products only. Confirm availability, price, lead time, local warranty, actual package and supplied regional variant separately.
