DS-2DE2A404IW-DE3

Manufacturer reference

Manufacturer details describe the cited version. Confirm the exact unit and intended system.

Imaging, lens and illumination

Device class

4 MP 4x IR network PTZ camera

Image sensor

1/3-inch progressive-scan CMOS optical format; not a measured sensor diagonal.

Maximum image resolution

2560 × 1440 pixels, manufacturer 4 MP class. This does not assign that resolution to every stream or output mode.

Low-light conditions

Colour 0.005 lux and black-and-white 0.001 lux at F1.6 with AGC on. The 0 lux condition requires IR. Not a field identification guarantee.

Shutter-time range

1 s to 1/30,000 s. Exposure affects motion and low-light results.

Day and night filter

An IR cut filter is listed. This alone is not proof of an IR illuminator, illumination range or a permanent-colour mode.

Optical zoom and lens

4x optical zoom with a 2.8–12 mm motorised lens. Confirm the required view; not the 32x dome lens.

Digital zoom

16x digital zoom. It does not multiply the optical-zoom specification into a new optical rating.

Aperture range

F1.6–F2.7. Lens aperture changes with zoom; do not assume the widest-aperture light condition at tele.

Focus modes

Auto, semi-auto and manual focus are listed.

Optical zoom time

Approximately 2 s from optical wide to tele; not a guaranteed field response time.

Wide-to-tele field of view

Horizontal 100°–33°, vertical 53°–18°, diagonal 119°–37.5°, from wide to tele.

Minimum working distance

10–1500 mm, wide to tele, is listed as the minimum-working-distance reference. It is not a target-identification distance.

IR illumination

IR range up to 20 m, with Smart IR listed. Scene and target conditions affect coverage; not guaranteed identification at 20 m.

Dynamic range

120 dB WDR is listed. This is not a backlit-scene recognition guarantee.

Image enhancement

3D DNR, HLC, EIS, regional exposure and regional focus are listed.

Privacy masks

24 programmable privacy masks are listed. Confirm actual masking and PTZ operation.

PTZ movement and controls

Pan movement

Pan 0–330°. This is not 360° endless pan.

Tilt movement

Tilt 0–90°. No negative-tilt range or auto-flip mode is inferred.

Pan speeds

Manual pan 0.1–100°/s; preset pan 100°/s.

Tilt speeds

Manual tilt 0.1–100°/s; preset tilt 100°/s.

Preset positions

300 preset positions are listed. Do not transfer a different dome model count.

Proportional zoom reference

Proportional zoom is listed. This is not automatic target tracking.

Power-off memory

Power-off memory is listed. It does not provide uninterrupted operation during an outage.

Streams, storage and connections

Video compression

Main stream: H.265+, H.265, H.264+ or H.264. Sub and third streams: H.265, H.264 or MJPEG. Confirm recorder and client support.

Video bitrate

32–16,384 kbps configurable reference. It does not establish a fixed retention duration or internet requirement.

Main-stream frame rates

24 fps at 2560 × 1440; 30 fps at 2048 × 1536, 1920 × 1080, 1280 × 960 or 1280 × 720. Do not label the 4 MP mode as 30 fps.

Sub-stream frame rates

30 fps at 704 × 480, 640 × 480 or 352 × 240.

Third-stream frame rates

30 fps at 1280 × 720, 704 × 480, 640 × 480 or 352 × 240.

ROI reference

Main, sub and third streams each support four fixed ROI areas. ROI is not an additional independent video stream.

Audio compression

G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2 and PCM are listed. Confirm actual audio settings and client support.

Card storage reference

MicroSD/SDHC/SDXC storage up to 256 GB is listed. Card supply, compatibility, filesystem, recording mode and retention need confirmation.

Network interface

One 10/100 Mbps RJ45 Ethernet port. Confirm the network and power arrangement.

API reference

The source names ONVIF, ISAPI, CGI and Hikvision SDK, with Hik-Connect mentioned. No specific ONVIF profile, certification, current service availability or universal recorder compatibility is established.

Live-view reference

Up to 20 live-view channels are listed. These are viewing sessions, not additional camera sensors or recorder inputs.

User accounts

Up to 32 users, with administrator, operator and user levels. Separate from the live-view-session limit.

Event reference

The source lists motion, tampering and exception events, plus face detection, line crossing, intrusion, region enter/exit, object removal, unattended baggage and audio exception detection. Face detection is not identity recognition or automatic PTZ tracking.

Recording recovery reference

ANR and dual-VCA are listed. Compatible card, recorder, firmware and recording settings require confirmation; not proof of cloud storage or an active ISD service.

Audio connections

One audio input and one audio output, with a built-in microphone listed. This does not establish a built-in speaker.

Power, physical limits and selection

Power reference

12 V DC or PoE (802.3af). Maximum 12 W is listed, with a separate maximum 3.9 W IR reference. Confirm the power source; do not add those figures into an invented total.

Operating conditions

-20 to +60 °C, humidity at most 90%, non-condensing. Confirm the actual site and enclosure conditions.

Protection reference

IP66 and IK10 are listed, with TVS 4000 V lightning, surge and voltage-transient protection references. These are not guarantees against every site exposure.

Body dimensions

Diameter 130.7 mm × height 101.7 mm in the table and whole drawing. The separate 118 mm annotation is not the overall body diameter.

Weight reference

Approximately 0.53 kg (1.17 lb). No packaged shipping weight is inferred.

Mounting selection

The source lists WMP-MPZ wall mount, PC120 pendant cap and CB120 conduit-base examples as not included. Confirm the complete mounting assembly before enquiry.

Selection notes

• This DS-2DE2A404IW-DE3 reference uses only its complete literal model and the cited regional document. Confirm supplied hardware, region, firmware, camera/recorder settings, power, mounts and package contents. Similar names or other suffixes are not interchangeable.
• Manufacturer references do not confirm stock, price, ETA, local warranty, authorisation, image rights or Malaysian compliance. ISD supplies products only.
• Confirm required output mode, power, recorder, card, cable, mounting and accessories. Regional packaging descriptions do not confirm the items ISD will supply.
• The complete DE3 suffix is required. No Wi-Fi, S6, C0 or bare-model equivalence is assumed; low-light and IR distances are not field-recognition guarantees.

Official documents

• Hikvision DS-2DE2A404IW-DE3 official regional datasheet

Manufacturer source checked 2026-10-20. The supplied unit and local terms require confirmation.
