DS-K1801E

Hikvision DS-K1801E is an EM card reader with Wiegand W26/W34 communication, a PC + ABS housing and IP65 protection. This variant has no keypad and supports card authentication.

Hikvision · Full reference: DS-K1801E

Choose quantity

Manufacturer reference

Manufacturer details describe the cited version. Confirm the exact unit and intended system.

Power

Power supply: 12 VDC, 0.15 A
Power consumption: ≤ 1.6 W

System

Processor: 8-bit
Watchdog: Supported

Interface

Communication protocols: Wiegand W26/W34

Authentication

Card reading range: ≤ 50 mm
Card type: EM
Keypad: No keypad
Authentication modes: Card
Card data reading: EM card number

Indicators

Buzzer: Built in
LED indicators: Power and status

General

Working temperature: -20 °C to 65 °C
Working humidity: 10% to 90% (non-condensing)
Dimensions: 87 × 87 × 13.3 mm
Ingress protection: IP65
Housing: PC + ABS
Weight: Gross: 0.22 kg; net: 0.14 kg (20240222 datasheet)

Selection notes

The documented specifications apply to the cited manufacturer version. Confirm the supplied hardware, firmware and accessory configuration.
0, 20170622; DS-K1801 datasheet 20240222 for E weight. Exact original model and route retained. Specifications are tied to the stated manufacturer document editions; supplied hardware, controller and firmware compatibility still require confirmation. The 20240222 PDF explicitly lists DS-K1801E as its available model and supplies E weights. Its family-level EM/M1 and keypad alternatives do not override the exact 2017 suffix mapping.
Readers, locks, power supplies, batteries, licences and other accessories are not assumed to be included. ISD confirms specification, compatibility, supply, price, lead time and local warranty separately.

Official documents

Manufacturer source checked 2026-09-10. The supplied unit and local terms require confirmation.
