DS-3WAP622E-SI

Manufacturer reference

Manufacturer details describe the cited version. Confirm the exact unit and intended system.

General

Weight

0.38 kg (0.83 lb)

Installation Mode

Desk-Mounted, Wall-Mounted, Ceiling Mounting

Working Temperature

0 °C to 45 °C (32 °F to 113 °F)

Working Humidity

5% to 95% (no condensation)

Storage Temperature

-40 °C to 70 °C (-40 °F to 158 °F)

Storage Humidity

5% to 95% (no condensation)

Product Dimensions (W × H × D)

220 mm × 220 mm × 39 mm

Packing List

3000 M Access Point ×1, Screw Pack × 1, Quick Start Guide ×1, Regulatory Compliance and Safety Information × 1

Power Consumption

Max. 13.5 W

WLAN Parameters

Maximum Number of Clients

256

Recommended Number of Clients

100

Maximum Number of SSIDs

8

Working Frequency Band

radio 1: 5G(11a/n/ac/ax), radio 2: 2.4G(11b/g/n/ax)

Wi-Fi Standards

Wi-Fi 6

Wi-Fi Speed

2.4 GHz: 575 Mbps; 5 GHz: 2400 Mbps

Spatial Streams

2.4 GHz, 2 × 2 , MU-MIMO, 5 GHz, 2 ×2 , MU-MIMO

Channel Width

2.4 GHz: Auto/20 /40 MHz,5 GHz: Auto/20 /40 /80/160 MHz

Number of Antennas

2.4GHz: 2; 5GHz: 2

Antenna Type

Built-in omnidirectional antennas

Antenna Gain

2.4 GHz: 3 dBi, 5 GHz: 4 dBi

Transmit Power

20 dBm

Modulation Technology

OFDM: BPSK@6/9Mbp, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps; DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps; MIMO-OFDM (11n): MCS 0-15; MIMO-OFDM (11ac): MCS 0-9; MIMO-OFDM (11ax): MCS 0-11

Software Specifications

WLAN Security

Blocklist and allowlist; multiple encryption keys; dynamic unicast/multicast key updates; open-system/shared-key authentication; wireless endpoint access; IEEE 802.11i; SSID and VLAN binding

Management & Maintenance

Centralized AC management

Version Upgrade

upgrade on AC Web

Hardware Specifications

Interface

1 × 2.5 Gigabit RJ45 uplink port

Power Supply

IEEE 802.3af/at POE, 12 VDC 1.5 A

LED Indicator

Yellow/green/blue for different working states, flashing mode

Reset Button

Hardware Resetting Button

Approval

EMC

CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020)

Safety

CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017), UL (UL 60950-1)

Chemistry

CE-RoHS (2011/65/EU), WEEE (2012/19/EU), Reach (Regulation (EC) No.1907/2006)

Radio

EN 301 893, EN 300 440, EN 62311, EN 301 489-3, E N 301 489-17

Selection notes

• The documented specifications apply to the cited manufacturer version. Confirm the supplied hardware, firmware and accessory configuration.
• Maximum client capacity and recommended client count are separate. Per-band PHY rates do not represent measured application throughput. Only source-confirmed original model/configuration values are included. No omitted suffix, hardware revision, regional order code, kit component, image or price is invented.
• Readers, locks, power supplies, batteries, licences and other accessories are not assumed to be included. ISD confirms specification, compatibility, supply, price, lead time and local warranty separately.

Official documents

• Hikvision DS-3WAP622E-SI manufacturer reference

Manufacturer source checked 2026-09-10. The supplied unit and local terms require confirmation.
